Email this article Development of technology for manufacturing electrodes for self-charging supercapacitors from carbon nanotubes
- Authors: Keller N.V.1, Nikolkin V.N.1, Butakov D.S.1, Zolotavin A.A.1, Askarova A.A.1, Kheynstein V.Y.1
-
Affiliations:
- JSC “Research Institute of Nuclear Material”
- Issue: Vol 60, No 7 (2024)
- Pages: 489-496
- Section: Articles
- URL: https://rjsvd.com/0424-8570/article/view/671298
- DOI: https://doi.org/10.31857/S0424857024070032
- EDN: https://elibrary.ru/PPYRTY
- ID: 671298
Cite item
Open Access
Access granted
Subscription Access
Abstract
The article discusses the development of the technology for manufacturing supercapacitor electrodes from industrially produced carbon nanotubes with a specific surface area of 109.6 m2/g, with the aim of further application in the manufacture of carbon electrodes for self-charging supercapacitors. The electrochemical characteristics of carbon nanotube electrodes were studied in a symmetrical two–electrode cell using cyclic voltammetry, galvanostatic charge-discharge, and impedance spectroscopy. It was shown that the specific capacitance of the electrode in the organic electrolyte 1-butyl-3-methylimidazolium trifluoromethane sulfonate:propylene carbonate (volume ratio 3:1) was 9.1 F/g.
About the authors
N. V. Keller
JSC “Research Institute of Nuclear Material”
Author for correspondence.
Email: keller_nv@irmatom.ru
Russian Federation, Zarechny, Sverdlovsk region
V. N. Nikolkin
JSC “Research Institute of Nuclear Material”
Email: keller_nv@irmatom.ru
Russian Federation, Zarechny, Sverdlovsk region
D. S. Butakov
JSC “Research Institute of Nuclear Material”
Email: keller_nv@irmatom.ru
Russian Federation, Zarechny, Sverdlovsk region
A. A. Zolotavin
JSC “Research Institute of Nuclear Material”
Email: keller_nv@irmatom.ru
Russian Federation, Zarechny, Sverdlovsk region
A. A. Askarova
JSC “Research Institute of Nuclear Material”
Email: keller_nv@irmatom.ru
Russian Federation, Zarechny, Sverdlovsk region
V. Y. Kheynstein
JSC “Research Institute of Nuclear Material”
Email: keller_nv@irmatom.ru
Russian Federation, Zarechny, Sverdlovsk region
References
- Conway, B. E., Electrochemical Supercapacitors: Scientific fundamentals and technological applications, N. Y.: Plenum Publ., 1999, p. 698.
- Иванов, A.M., Герасимов, А.Ф. Молекулярные накопители электрической энергии на основе двойного электрического слоя. Электричество. 1991. Т.1. С. 16. [Ivanov, A.M. and Gerasimov, A.F., Molecular energy storage devices based on electrical double layer, Russ. J. Electric., 1991, vol. 1, p. 16.]
- Рисованый, В.Д., Булярский, С.В., Марков, Д.В., Синельников, Л.П., Николкин, В.Н., Злоказов, С.Б., Джанелидзе, А.А., Светухин, В.В. Суперконденсатор и способ его изготовления, Пат. 2668544 (Россия), 2018. [Risovanyj, V.D., Bulyarskij, S.V., Markov, D.V., Sinelnikov, L.P., Nikolkin, V.N., Zlokazov, S.B., Dzhanelidze, A.A., and Svetukhin, V.V., Supercapacitor and its manufacturing method, Patent 2668544 (Russia), 2018.]
- Рисованый, В.Д., Костылев, А.И., Душин, В.Н., Фирсин, Н.Г., Синельников, Л.П., Бутаков, Д.С., Николкин, В.Н. Атомные батареи конденсаторного типа нового поколения с жидким электролитом. Атомная энергия. 2022. Т. 132. С. 175. [Risovanyj, V.D., Kostylev, A.I., Dushin, V.N., Firsin, N.G., Sinelnikov, L.P., Butakov, D.S., and Nikolkin, V.N., New generation atomic batteries of capacitor type with liquid electrolyte, Russ. J. Atomic energy, 2022, vol. 132, p. 175.]
- Signorelli, R., Ku, D.C., Kassakian, J.G., and Schindall, J.E., Electrochemical Double–Layer Capacitors Using Carbon Nanotube Electrode Structures, IEEE, 2009, vol. 97, no. 11. p. 1837.
- Чернявина, В. В., Бережная, А. Г., Жихарева, Е.А. Активированный уголь марки “NORIT B Test EUR” как электродный материал суперконденсатора. Электрохим. энергетика. 2018. Т. 18. № 4. С. 192. [Chernyavina, V.V., Berezhnaya, A.G., and Zhikhareva, E.A., Activated carbon “NORIT B Test EUR” as an electrode material for supercapacitors, Russ. J. Electrochemical Energetics, 2018, vol. 18, no. 4, p. 192.]
- Чайка, М.Ю., Воробьев, А.Ю., Силютин, Д.Е., Небольсин, В.А. Разработка лабораторного технологического маршрута изготовления нанопористых электродов суперконденсаторов. Вестник ВГУ. 2012. Т. 7, № 2. С. 79. [Chayka, M.Yu., Vorobjev, A.Yu., Silyutin, D.E., and Nebolsin, V.A., Development of the laboratory technological route for supercondensers nanoporous electrodes manufacturing, Russ. J. Vestnik VSU, 2012, vol. 7, no. 2, p. 79.]
- Янилкин, И.В., Саметов, А.А., Школьников, Е.И. Влияние количества связующего фторопласта Ф4 в угольных электродах на характеристики суперконденсаторов. Журн. прикл. химии. 2015. Т. 88. №2. С. 336. [Yanilkin, I.V., Sametov, A.A., and Shkol’nikov, E.I., Impact of F-4 fluoroplast in carbon electrodes on the supercapacitors characteristics, Russ. J. applied chemistry, 2015, vol. 88, no. 2. p. 336.]
- Lalitha, M. and Lakshmipathi, S., Interface energetics of [Emim]+[X]− and [Bmim]+[X]− (X = BF4, Cl, PF6, TfO, Tf2N) based ionic liquids on graphene, defective graphene, and graphyne surfaces, J. Molecular liquids, 2017, vol. 236, p. 124.
- Lam, P.H., Tran, A.T., Walczyk, D.J., Miller, A.M., and Yu, L., Conductivity, viscosity, and thermodynamic properties of propylene carbonate solutions in ionic liquids, J. Molecular liquids, 2017, vol. 246, p. 215.
- Di Leo, R.A., Marschilok, A.C., Takeuchi, K.J., and Takeuchi, E.S., Battery electrolytes based on saturated ring ionic liquids: Physical and electrochemical properties, Electrochim. Acta, 2013, vol. 109, p. 27.
- Pitawela, N.R. and Shaw, S.K., Imidazolium triflate ionic liquid’s capacitance−potential relationships and transport properties affected by cation chain lengths, ACS Meas. Sci, 2021, vol. 1, p. 117.
