Studying the evolution of the power spectra of acoustic radiation during the destruction of a solid body

Cover Page

Cite item

Full Text

Open Access Open Access
Restricted Access Access granted
Restricted Access Subscription or Fee Access

Abstract

When interpreting acoustic emission (AE) observation data, a model of a crack in the form of a cavity in the shape of an oblate ellipsoid of revolution was used. When the length of its semi-minor axis tends to zero, the ellipsoid models a circular disc-shaped crack. Using data from two amplitude-frequency spectra of AE recorded during the destruction of a concrete sample, distributions of the power of acoustic radiation along the lengths of the semi-axes of the ellipsoidal cavities were constructed. It is shown that by the time the second spectrum is recorded, a redistribution of acoustic radiation occurs in favor of a discrete set of growing main cracks with high semi-major axis lengths and a small opening value.

About the authors

V. T. Belikov

Institute of Geophysics UrB RAS

Author for correspondence.
Email: belik2a@mail.ru
Russian Federation, 620016 Yekaterinburg, Amundsen st., 100

References

  1. Regel V.R., Slutsker A.N., Tomashevsky E.E. Kinetic nature of the strength of solids. Moscow: Nauka, 1974. 560 p.
  2. Panin V.E., Likhachev V.A., Grinyaev Yu.V. Structural levels of deformation of solids. Novosibirsk: Nauka, 1985. 255 p.
  3. Parton V.S., Morozov E.M. Mechanics of elastoplastic fracture. Moscow: Nauka, 1985. 504 p.
  4. Belikov V.T., Ryvkin D.G. Study of the development regimes of the destruction process based on observational data of acoustic emission // Physical mesomechanics. 2017. V. 20. No. 4. P. 77—84.
  5. Greshnikov V.A., Drobot Yu.B. Acoustic emissions. Moscow: Publishing house of standards, 1976. 272 p.
  6. Baranov V.M. Acoustic measurements in nuclear power. Moscow: Energoatomizdat, 1990. 320 p.
  7. Buylo S.I. Physico-mechanical, statistical and chemical aspects of acoustic emission diagnostics. Rostov-on-Don: Southern Federal University Publishing House, 2017. 184 p.
  8. Aleinikov A.L., Belikov V.T., Nemzorov N.I. Acoustic emission in heterogeneous media // Defectoscopiya. 1993. No. 3. P. 31—36.
  9. Stepanova L.N., Petrova E.S., Chernova V.V. Strength testing of a carbon fiber spar using acoustic emission and strain gauge methods // Defectoscopiya. 2018. No. 4. P. 24—30.
  10. Chernov D.V., Matyunin V.M., Barat V.A., Marchenkov A.Yu., Elizarov S.V. Study of the patterns of acoustic emission during the development of fatigue cracks in low-carbon steels // Defectoscopiya. 2018. No. 9. P. 21—30.
  11. Stepanova L.N., Chernova V.V., Kabanov S.I. Analysis of the processes of destruction of carbon fiber samples using acoustic emission and strain measurement // Defectoscopiya. 2023. No. 7. P. 3—13.
  12. Niccolini G., Schiavi A., Tarizzo P., Carpinteri A., Lacidogna G., Manuello A. Scaling in temporal occurrence of quasi-rigid body vibration pulses due to macro-fractures // Phys. Rev. E. 2010. V. 82. No. 4. P. 046115 (1—5).
  13. Schiavi A., Niccolini G., Tarizzo P., Carpinteri A., Lacidogna G., Manuello A. Acoustic emissions at high and low frequencies during compression tests in brittle materials // Strain. 2011. V. 47. No. 2. P. 105—110.
  14. Belikov V.T., Ryvkin D.G. Using the results of observations of acoustic emission to study the structural characteristics of a solid body // Acoustic Journal. 2015. V. 61. No. 5. P. 622—630.
  15. Panteleev I.A. Analysis of the seismic moment tensor of acoustic emission: micromechanisms of granite destruction under three-point bending // Acoustic Journal. 2020. V. 66. No. 6. P. 654—668.
  16. Belikov V.T. Interpretation of the results of observations of acoustic emission in a collapsing solid // Applied mechanics and technical physics. 2023. V. 64. No. 3. P. 199—206. doi: 10.15372/PMTF202215200
  17. Sedov L.I. Continuum mechanics. V. 2. Moscow: Nauka, 1984. 560 p.
  18. Belikov V.T. Conditions for the implementation of possible modes of development of the process of destruction of a solid body, Izvestiya RAS // Mechanics of solids. 2020. No. 2. P. 28—39. doi: 10.31857/S0572329920010055
  19. Isakovich M.A. General acoustics. Moscow: Nauka, 1973. 496 p.
  20. Norden A.P. Short course in differential geometry. Moscow: Fizmatgiz, 1958. 244 p.
  21. Belikov V.T., Ryvkin D.G. Study of changes in the structural characteristics of a solid using amplitude-frequency spectra of acoustic emission // Physical mesomechanics. 2016. V. 19. No. 3. P. 103—109.
  22. Alder P.M. Porous media: geometry and transports. Stoneham: Butterworth-Heinemann, 1992. 544 p.
  23. Levin V.A., Morozov E.M., Matvienko Yu.G. Selected nonlinear problems of fracture mechanics.Moscow: Fizmatlit, 2004. 408 p.
  24. Parton V.Z. Fracture mechanics from theory to practice. Moscow: Nauka, 1990. 240 p.
  25. Landau L.D., Lifshits E.M. Statistical physics. Moscow: Nauka, 1964. 568 p.
  26. Bazarov I.P. Thermodynamics. Moscow: Higher School, 1991. 376 p.
